Name: Mainboard Gigabyte B365M-D2V
Brand: GIGABYTE
SKU: tnm1719
Availability: InStock
Rating: 5 (1 reviews)

Mã Sản phẩm: tnm1719

Liên hệ

Mainboard Gigabyte B365M-D2V

Ngày đăng: 03-05-2019

Ngày sửa cuối: 09-05-2021

Thương hiệu: GIGABYTE

Mục	Mô Tả Chi Tiết
CPU	Support for 9th and 8th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package L3 cache varies with CPU
RAM	2 x DDR4 DIMM sockets supporting up to 32 GB of system memory Dual channel memory architecture Support for DDR4 2666/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Khe cắm mở rộng	1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.)
Chipset	Intel® B365 Express Chipset
Giao tiếp	Chipset: 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Kết nối mạng LAN	Realtek® GbE LAN chip (10/100/1000 Mbit)
Âm thanh	Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel
Hệ điều hành hỗ trợ	Support for Windows 10 64-bit
Cổng I/O phía sau	1 x PS/2 mouse port 1 x PS/2 Keyboard port 1 x D-Sub port 1 x DVI-D port 4 x USB 3.1 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks
Cổng I/O ở trong	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x Clear CMOS jumper
Kích thước	Micro ATX Form Factor; 22.6cm x 18.5cm
Bảo hành	36 tháng
