Mainboard Gigabyte B560M AORUS PRO

  • : tnm7239
  • Giá bán : liên hệ
  • Chipset: Intel® B560 Express Chipset
  • CPU hỗ trợ: 11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors* * Limited to processors with 4 MB Intel® Smart Cache, Intel® Celeron® G5xx5 family. L3 cache varies with CPU
  • Socket: LGA1200
  • Lưu trữ: CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)* * Supported by 11th Generation processors only. Chipset: 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB) 6 x SATA 6Gb/s connectors * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors. Intel® Optane™ Memory Ready
Thông số kỹ thuật
Loại Ram :
Đang cap nhat
Chipset :
Intel® B560 Express Chipset
Socket :
LGA1200
Khe Ram :
Đang cap nhat
Dung lượng Ram hỗ trợ tối đa :
Đang cap nhat
Tốc độ Bus :
Đang cap nhat
Cổng xuất hình :
1 x DisplayPort, 1 x HDMI port
Wifi :
Đang cap nhat
Bluetooth :
Đang cap nhat
Kết nối mạng LAN :
Intel®2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
Khe cắm :
Đang cap nhat
Khe PCI :
1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 4.0 standard.)* *Supported by 11th Generation processors only. 1 x PCI Express x16 slot, running at x4 (PCIEX4) 1 x PCI Express x1 slot (The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)
Số cổng USB :
Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen2x2 support 1 x USB 3.2 Gen2 Type-A ports (red) on the back panel 2 x USB 3.2 Gen1 ports on the back panel 2 x USB 2.0/1.1 ports on the back panel Chipset+USB 3.2 Gen 1 Hub: 1 x USB Type-C® port with USB 3.2 Gen1 support, available through the internal USB header 2 x USB 3.2 Gen1 ports available through the internal USB header Chipset+ 2 USB 2.0 Hub: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Hệ điều hành hỗ trợ :
Support for Windows 10 64-bit
Kích thước :
Micro ATX Form Factor; 24.4cm x 24.4cm
Bảo hành :
36 tháng
Hãng sản xuất :
Gigabyte
Mô tả tính năng
Đang cập nhật
